SKU: DS/7104HGHI/M1
HIKVISION 4 CHANNEL CCTV DVR
HIKVISION 4 CHANNEL CCTV DVR
In stock
Description
Description
The Hikvision 4‑Channel DVR is a compact yet powerful video recorder — ideal for homes, small businesses, shops, or small‑scale security setups. It supports up to four analog CCTV cameras (and often allows addition of IP cameras), giving you flexible coverage for entrances, driveways, yards, or indoor spaces.
With support for multiple video standards (HD‑TVI, AHD, CVI, CVBS), the DVR works with a broad range of cameras — from traditional analog cameras to newer HD variants. It records in Full HD (1080p) (or 1080p‑lite / 720p depending on load), capturing clear footage for surveillance, security, and monitoring needs. Video is compressed using H.265/H.264 for efficient use of storage and bandwidth without sacrificing quality.
Key Specifications
-
Channels: 4 analog channels (supports HDTVI / AHD / HDCVI / CVBS) — plus many models also allow additional IP‑camera input.
-
Supported Video Formats: HD‑TVI, AHD, HDCVI, CVBS; many are “Turbo HD / Hybrid” DVRs allowing mixed analog + IP cameras.
-
Recording Resolution: Up to 1080p (Full HD) or “1080p‑lite” for all channels; also supports 720p / WD1 / 4CIF / CIF depending on camera & settings.
-
Video Compression: H.265 Pro+ / H.265 / H.264+ / H.264 — efficient compression to save storage and bandwidth.
-
Video Output: 1 × HDMI and 1 × VGA output; supports up to 1080p (Full HD) on monitors/TVs.
-
Audio: 1‑channel audio input (RCA / coax depending on camera) + 1‑channel audio output (RCA). Supports audio recording when using cameras with mic/audio support.
-
Storage: 1 SATA bay for HDD — supports large capacity hard drives (often up to 4 TB, depending on model).
-
Recording Modes: Continuous, scheduled, motion‑detection, event‑triggered (depending on model), for flexible surveillance setups.
-
Playback: Multi‑channel synchronous playback (up to 4 channels) for reviewing recorded footage.
-
Network / Remote Access: Ethernet (RJ‑45) network port — enables remote viewing/access via network or compatible apps (for supported models).
-
Supported Protocols: TCP/IP, DHCP, DDNS, NTP, HTTP/HTTPS, and more (depending on DVR firmware) for network connectivity and remote management.
-
Power Supply: 12 V DC (typical), with modest power consumption (varies by whether HDD is installed).
-
Operating Conditions: Typical analog‑DVR tolerances (e.g. -10 °C to +55 °C, humidity 10%–90% non‑condensing) — suitable for indoor installation.
