SKU: KC3E/240A
ONESTO DIN RAIL 40A 3KA 2P CIRCUIT BREAKER
ONESTO DIN RAIL 40A 3KA 2P CIRCUIT BREAKER
In stock
Description
Description
The Onesto 40 A 2P 3 kA Mini Circuit Breaker is a robust and dependable over‑current protection device — ideal for residential, commercial, or light‑industrial installations where enhanced circuit safety is needed. With its double‑pole design, the breaker disconnects both live and neutral conductors (or both phases where applicable), ensuring full isolation and higher safety compared to single‑pole breakers.
Designed for circuits with higher load demands, this breaker delivers 40 A rated current and a short‑circuit breaking capacity of 3 kA, effectively safeguarding wiring and connected equipment against overloads or short‑circuit faults. The thermo‑magnetic (C‑curve) tripping mechanism responds quickly and reliably to fault conditions, while DIN‑rail mounting ensures straightforward installation in standard distribution boards or breaker panels.
-
Type: Miniature Circuit Breaker (MCB), Double‑Pole (2P)
-
Rated Current (In): 40 Amps — suitable for medium‑ to high‑load single‑phase circuits requiring 40 A protection.
-
Number of Poles / Configuration: 2‑pole — disconnects both live and neutral (or both phases in certain systems), offering full circuit isolation.
-
Breaking Capacity (Icu / Ics): 3 kA — safely interrupts overloads or short‑circuit fault currents up to 3,000 A.
-
Voltage Rating: ~220 VAC (domestic supply) — the listed spec is 220 V for this variant.
-
Tripping Curve / Characteristic: C‑curve (thermo‑magnetic) — suitable for general‑purpose circuits, with balanced sensitivity and inrush‑current tolerance.
-
Mounting / Form Factor: DIN‑rail mount — standard 35 mm rail compatible for easy installation in distribution boards/panels.
-
Protection Provided: Overload protection and short‑circuit protection — protects wiring and connected devices from faults, surges, and overloads.
-
Typical Applications: Domestic and light‑commercial installations — suitable for heavier socket circuits, power outlets for larger appliances, sub‑circuits requiring 40 A dual‑pole protection.
